13-60
13-60 Technical Specifications:
Chassis Specifications:
- Construction S700MC high strength steel
- Axle: Özkoç Trax/Sertel, with drum
- Suspension 813 single layer truss
- Tire/Rims: 385/65/R22.5, 6 pcs
- Brake Wabco/Knorr EBS system
- Electricity Sa-Ba LED lighting set
Accessories
- Cabinets 120 cm x 1.2 mm sheet metal, 1 piece
- Spare Wheel Carrier: Tubular type for single wheel
- Safety Plastic wheel chock, fire extinguisher cabinet
- Mudguard Separate for each wheel, total 6 pieces
Case Specifications:
- Base MDF or wood option
- Cover 1.2 mm Domex sheet
- Supports S700 MC steel bollard and base supports
Paint and Coating:
- Process: Sandblasting, epoxy primer, acrylic topcoat
- Color Chassis RAL 7016, body customer choice
Additional Features:
- Manometer with load indicator
- Wide grain cover
- Manual front/mid axle lift system
- TSE/TUV compliant safety equipment
- 2 plastic lockers under the front stairs
13-60 Technical Drawing:
